Title: MUTOH PJ-1614NXE, PJ-2216NXE Series Service Manual (Direct Download)
Format: PDF
Size: 14 MB
Description: This manual explains preparations needed before using and procedures for operations for MUTOH INDUSTRIAL LTD. Grand Format Inkjet Printer(PJ-1614NXE,PJ-2216NXE); use the built-in self-diagnostic program to locate a defective part and adjust/check during maintenance; and before using this printer, first understand the contents and directions in this manual.
Content Abstract:
This manual consists of nine chapters and appendix.
CHAPTER 1 Safety Instructions. Explains types of warnings, cautions and warnings labeled on the printer for the both operators of the printer and maintenance personnel.
CHAPTER 2 Product Overview. Explains the features, part names, and functions of the printer.
CHAPTER 3 Specifications. Explains the specifications of the printer.
CHAPTER4 Procedures of parts replacement. Explains the procedures of replacement and removal of the service parts of the printer.
CHAPTER 5 Self diagnostic function. Explains the self diagnostic functions of the printer.
CHAPTER 6 Maintenance mode. Explains the maintenance mode of the printer.
CHAPTER 7 Adjustment. Explains the adjusting procedures of the Printer Parts.
CHAPTER 8 Maintenance. Explains daily maintenance of the printer.
CHAPTER 9 Troubleshooting. Explains troubles that may occur when using the printer and how to solve them.
APPENDIX:
Explains the specifications, optional parts and supplies, installation procedures for optional parts, and user support for this printer.
• Introduction
• Wiring Diagram
• Jig and Tool List
• Exploded View/Service Parts List
Notice:
1. You can download the PDF when the payment is made.
2. If you can't find the document that you need, please just click "Ask a Question" Button above to leave us a message.
